Semi Automatic CIP Cleaning System

The semi automatic CIP cleaning system consists of acid tanks, alkali tanks, hot water tanks, heat exchangers, process pumps, return pumps, diaphragm pumps, control boxes, various pipelines, and sanitary valves.

Product Features

1. Improve cleaning efficiency and product safety;

2. It can automatically adjust the temperature of various levels of water, acid, alkali cleaning solution, and hot water;

3.Compared with manual CIP cleaning systems, automated programs are higher and labor costs are lower;

4. In response to customers' special requirements, programs can be developed or modified on-site;

5. According to customer requirements, centralized control and operation records can be achieved;

6. The semi automatic CIP cleaning system can be single or multiple tanks for users to choose from, and can also be mobile or fixed.

Application field

Process procedure for CIP cleaning

Taking the beverage industry as an example, the cleaning process procedure is as follows:

1. Start cleaning with hot water at room temperature or above 60℃ for 3-5 minutes; Wash with a 1% -2% solution at 60 ℃-80℃ for 10-20 minutes with alkali; Then rinse with clean water below 60℃ for 5-10 minutes; Finally, rinse with clean water for 3-5 minutes.

2. Start cleaning with hot water at room temperature or above 60℃ for 3-5 minutes; Wash with a 1% -2% solution at 60℃ -80℃ for 5-10 minutes with alkali; Then rinse with clean water below 60℃ for 5-10 minutes; Finally, disinfect with hot water at 90℃ for 10-20 minutes.

The cleaning flow rate is for the purpose of maintaining the flow rate of the cleaning solution, thereby producing a certain effect and achieving a good cleaning effect.
