Duplex Filter

Intop is a supplier of duplex filter. Sanitary grade duplex filters are suitable for purifying liquids such as fresh milk, sugar syrup, and beverages, and can effectively remove solid substances that cannot be seen by the naked eye from the barrel.

Send Inquiry

Product Description

Duplex filter, also known as dual switching filter, is composed of two sanitary grade filters connected in parallel. It has the characteristics of reasonable structure, good sealing, strong flow capacity, and easy operation. In the food and beverage industry, the purity and quality requirements for products are extremely high. Our duplex filter can provide reliable guarantee for the hygiene and safety of products. Especially suitable for scenarios that require long-term continuous production, the two filters can be used alternately to achieve non-stop replacement or cleaning of the filter screen, greatly improving production efficiency.

Duplex Filter

Product Technical Parameters

Model	SL-01	SL-02
Filtration area(m2)	0.15	0.3
Filtration capacity(t/h)	5	10
Inlet and outlet pipe diameter	32mm	40mm
Applicable Temperature	<=120℃
Filter aperture	60-400
Work pressure	<=0.2Mpa
Filter material	304/316L
Surface treatment method	Internal and external mirror polishing

Product structure

The duplex filter consists of multiple components, including: 1.Filter 2. Three-way external threaded plug 3. Round nut 4. Right angle bend 5. Optical joint 6. Threaded joint 7. Stainless steel pipe 8. Cap nut 9. Tightening bolt 10. Handle

Duplex Filter

Hot Tags: Duplex Filter Manufacturer, Industrial Duplex Filter Supplier, High Pressure Duplex Filter Wholesale
