Gable Top Carton Filling Machine

Characteristics of roof box packaging

Roof shaped packaging, due to its unique shape, beautiful patterns, environmentally friendly materials, and convenient use, makes this product high-end and profitable. It highlights its characteristics in the packaging market of a wide variety of liquid products and also allows enterprises to earn considerable profits. The production process of gable top carton packaging products is more convenient and feasible than any other type of packaging. Its characteristics are:

1. No need for a large packaging warehouse, no need for large transportation costs, one cardboard box can hold nearly a thousand packaging cardboard sheets;

2.Two packaging boxes can be directly loaded onto the machine without cleaning, which can save a lot of water, electricity, labor, equipment costs, etc;

3.The area requirement for the production workshop is not large, and the cost of building the factory is low;

4.Production workers require a small quantity and have low wage costs.

Equipment Technical Parameters

Application field

Gable top carton filling machine is widely used for filling liquid, granular or powder products such as fruit juice drinks, fruit vinegar drinks, grain drinks, tea drinks, cream, pure milk, soy milk, fermented yogurt, dairy drinks, seasonings, alcoholic beverages, chemicals or grains.

Production process flow

Gable top carton filling machine is mainly divided into two major steps in the production process: box making and filling

1. Box making production process: roof box paper sheet → manual box loading → manual bottom pre folding → bottom heating → pressure sealing forming → opening paper closure.

2. Capping machine: manual lid placement → manual box placement → ultrasonic welding → opening and covering paper box

3. Filling production process: manual box placement onto the track → top pre folding → filling → top sealing and forming → printing date → the entire operation process of the roof packaging product filling machine is automatically controlled by computer programs, while the rest is automatically controlled by electrical appliances.
