Pulping Machine

The pulping machine is suitable for pulping and separating crushed fruits such as tomatoes, kiwis, strawberries, apples, pears, as well as pre cooked and softened fruits such as hawthorn and dates. And it has the following characteristics:

1. Automatic separation of pulp and slag.

2. It can be combined on the production line or produced individually.

3. The parts in contact with the materials are made of high-quality stainless steel, which meets food hygiene standards.

Product structure

The pulping machine consists of the following components: 1. Transmission system 2. Bearing seat 3. Cylinder back cover 4. Slurry baffle 5. Cylinder body 6. Spline shaft 7. Screen 8. Scraper 9. Adjustment seat 10. Cylinder front cover 11. Rack

Product Technical Parameters

Product working principle

The electric motor is driven by a belt to rotate the scraper installed on the spline shaft at high speed. When the crushed fruit enters the pulping machine through the feeding port, the pulp tray evenly discharges the material to the scraper and screen. Due to the rotating effect of the scraper and the existence of the lead angle, the material moves along the cylinder towards the outlet end, with a spiral trajectory. The material is scraped by centrifugal force during the movement between the scraper and the sieve cylinder, and the juice and meat are sent into the next process through the sieve holes. The skin and seeds are discharged from the slag hopper to achieve automatic separation. By changing the size of the sieve and adjusting the lead angle of the scraper, different beating speeds can be changed to achieve satisfactory results.
